Casambi Motion Sensor
with brightness sensor for surface mounting.
Variants and options
FEATURES
- Assign the desired scenes to the sensor via app
- Luminaires automatically switch on and off after motion detection
- Reduce energy consumption
- Integrated brightness sensor – separate use possible
- Absence setting – changing the dimming level during absence
- Day and night setting – individual light at certain times when motion is detected
- Activate/deactivate automation by motion detector via switch or timer
- iBeacon can be activated
ITEM NUMBER
- 1038
- PIR motion detector + brightness sensor for ceiling mounting / surface mounting, detection angle 5-7m
Technical details
- Operating Voltage
- 220–240 VAC, 50/60 Hz
- Network
- Bluetooth Mesh Technology
- DETECTION ZONE
- 5-7 m
- SENSOR SWITCH-ON TIMES
- adjustable via app, up to 60 mins.
- SENSOR PHOTOSENSITIVITY
- adjustable via app, up to 2000 Lux
- PROTECTION CLASS
- IP 20
- DIMENSIONS
- Ø 91 mm x 45 mm
- HOUSING COLOUR
- White matt (RAL 9003)
- COMPATIBILITY
- Casambi, Occhio Air
DOWNLOADS
Smart control
Design your individual light, control luminaires and devices with the Casambi app. Switch your scenes via smartphone or wall switch.
Dimming and switching
Infinitely variable brightness control, switching of one or more luminaires and devices.
Create scenes
Create scenarios and retrieve or automate them as needed.
Switching options
Stage atmosphere with the push of a button, motion detector or synchronised to sunrise and sunset times.
